Gigabyte B650-EAGLE-AX B650 EAGLE AX WIFI 6E AMD B650 Ryzen Socket AM5 ATX Desktop Motherboard
Pricing visible is already subject to a 2% discount applicable only to EFT payments.
Configure
Build to orderWiFi & Bluetooth AdapterNone selected
ASUS WiFi 7 Tri-Band PCIe Wireless Adapter View
Overview
SPECIFICATIONS
- Brand
- Gigabyte
- Series
- EAGLE Series
- Model
- B650 EAGLE AX (B650-EAGLE-AX)
- CPU Support
- Supports Ryzen 7000 & 8000 Series Processors
- Chipset
- AMD B650 Chipset
Memory Support
- AMD B650 Chipset
- Support for DDR5 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800 MT/s memory modules
- 4x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
- Dual channel memory architecture
- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
- Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules
Video
- DisplayPort
- 1x DisplayPort 1.4 Port, supporting a maximum resolution of 3840x2160@144 Hz, supports HDCP, HDR, FreeSync
- HDMI
- 1x HDMI 2.1 Port, supporting a maximum resolution of 4096x2160@60 Hz, supports HDCP, HDR, FreeSync
- Integrated graphics required. Actual support may vary by CPU.
Expansion Slots
- CPU Direct
- 1x PCIe 4.0 x16 Electrical Slots (x16 Physical)(PCIEX16)
- AMD B650 Chipset
- 3x PCIe 3.0 x1 Electrical Slots (x16 Physical)
- Slot Configurations
- PCIEX16 with Ryzen 8000 Phoenix 1 Processors support PCIe 4.0 x8 mode
- PCIEX16 with Ryzen 8000 Phoenix 2 Processors support PCIe 4.0 x4 mode
- The PCIEX1_1 and PCIEX1_2 slots become unavailable when an AMD Ryzen 8000 Series-Phoenix 2 processor is used.
Storage
- CPU Direct
- 1x M.2 25110 / 2580 PCIe 5.0 x4 NVMe SSD Slot (M2A_CPU)
- 1x M.2 22110 / 2280 PCIe 4.0 x2 NVMe SSD Slot (M2P_CPU)
- AMD B650 Chipset
- 1x M.2 22110 / 2280 PCIe 4.0 x4 NVMe SSD Slot (M2C_SB)
- 4x SATA 6Gb/s connectors
- RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
- RAID 0, RAID 1, and RAID 10 support for SATA storage devices
- Storage Configurations
- M2A_CPU with Ryzen 8000 Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
- M2A_CPU with Ryzen 8000 Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
- M2P_CPU with Ryzen 8000 Phoenix 1 Processors support PCIe 4.0 x2 SSDs
- M2P_CPU with Ryzen 8000 Phoenix 2 Processors support PCIe 4.0 x2 SSDs
Additional information
- Manufacturer's Site
- Visit the manufacturer's website
- Product Link
- Visit the manufacturer's page for this product
Customer reviews
- ★★★★★ 5.0Edwin
Great AM5 Motherboard
This board offers great value for money and covers everything needed for a modern system, with enough headroom for future upgrades on the AM5 platform.
- Product Rating5/5
- ★★★★★ 5.0Cam
Awesome
Starting my first ever PC build and I could not think of any better motherboard to get me started. With AM5 support and 3 M.2 slots its future proof and gives plenty of space to upgrade storage down the line. Not to mention the clean design that's very appealing to the eye! I live south of Johannesburg and I received the product in record time. Its safe to say that I will be buying all my future parts from Wootware.
- Product Rating5/5
- ★★★★★ 2.0Lyall
Rather look for something else
I bought this motherboard less than a year ago (2024) and it failed on me because of the load shedding introduced this year (2025). Now I didn't use a surge protector? Yes, that my fault. But let me say this... I had a Gigabyte GA-Z97-D3H (DDR3 RAM) motherboard that survived the "rolling blackouts" we had during the period of 2021 and 2022. 2022 had 208 days of load shedding. My old motherboard survived all this "without a surge protector"! So, I cannot give this motherboard a pass. Also, the onboard Bluetooth is extremely bad. Driver issues, bad connections, sometime just do not connect. It's better just to buy a cheap dongle. All the other features on the board are fine though.
- Product Rating2/5
- ★★★★★ 5.0Bradley
First AM5 Build
Great product, highly recommended for those upgrading to AM5 and as always exceptional service from Wootware!
- Product Rating5/5
- ★★★★★ 5.0Miguel
Highly recommend
Easy to build with and high quality. The only issue I had was that I pulled the USB 3.2 plastic seat on the USB 3.2 header completely off the board when trying to unplug the cable, luckily, I was able to re-attach the plastic seat back over the pins without breaking anything, but this was more the fault of inexperience rather than the quality of the product.
- Product Rating5/5
- ★★★★★ 5.0Rishane
Gaming Build
Board does not disappoint. GCC (desktop) software allows you to tune fans and select RGB lights individually or in sync.
- Product Rating5/5
- ★★★★★ 5.0Christo
Going AM5
This was part of my "upgrade into AM5", away from intell-11. Always been a Gigabyte fan, and this board does not dissappoint.
- Product Rating5/5
- ★★★★★ 5.0Juan
Home PC
Great Graphics quality and rendering super! Layout and slots provide awesome functionality and upgrade ability. Great speed and value with my new setup. Moar Memory is always great \o/
- Product Rating5/5
- ★★★★★ 5.0Daniel
Exceptional
I never truly realised the amount of features this board provides for the price. It has bluetooth, wifi and this may be a small thing, but the NVMe slots have a neat little plastic pin which means you don't need to use a screw. It blew my mind.
- Product Rating5/5
